L7806CV +6V 1A Voltage Regulator

L7806CV +6V 1A Voltage Regulator

Please Note: This product can only be bought instore and not online, we recommend contacting us for availability before making a special visit to our shop

£1.99
£1.99
Sale Sold out
Shipping calculated at checkout.
Contact us for availability
Order Code: 04-163

This three-terminal single output 6V fixed positive voltage regulator can deliver 1A of regulated output current. Although designed primarily as a fixed voltage regulator, this devices can be used with external components to obtain adjustable voltages and currents.

Specifications
Output Current (Max)1A
Output Voltage6V
Minimum Input Voltage8V
Maximum Input Voltage35V
PolarityPositive
Pins3
MountingThrough Hole
Temperature Rating0°C to 125°C
CasingTO-220
Tolerance2 % output voltage tolerance
ProtectionThermal overload protection, Short circuit protection, Output transition SOA protection
