On-Off Momentary Toggle Switch SPST
On-Off Momentary Toggle Switch SPST
Please Note: This product can only be bought instore and not online, we recommend contacting us for availability before making a special visit to our shop
Regular price
£3.99
Regular price
Sale price
£3.99
Unit price
per
Shipping calculated at checkout.
Contact us for availabilityOrder Code: 14-145
Momentary toggle switch with an Off-(On) action suitable for panel mounting.
Specifications
| Type | Toggle |
| Action | Momentary (non-locking) |
| Pole Configuration | SPST |
| Positions | On (Non-Locking) Off (Locking) |
| illumination | None |
| Max Voltage & Current | 15A 250VAC |
| Contact Resistance | 25mΩ Max |
| Insulation Resistance | 100MΩ Min |
| Dielectric Strength | 1000VAC 1 minute |
| Panel Cut-Out Size | 12mm |
| Cycle Life | 100,000+ Cycles |
| Dimensions | 55.5 x 29.6 x 16mm (Height x Length x Width) |
| Operating Temperature | -25°C to +80°C |
| Number of Terminals | 2 |
| Terminal Type | 6.3mm |
